A0808N
8-in 8-out Audio Processor with Dante
Features
- Open Architecture-Drag & Drop DSP
- Innovative ACX Designer software for MAC & PC
- Premium Grade Mic Pre-Amps
- Mic/Line Input Selection per Input with 48V Phantom Power
- Ethernet Connectivity and Control
- Use our Free ACXTouch Software on your Android Device to Control Neutrino
- Third Party Control
Request a quote
Quote
"*" indicates required fields
- Great Technical Support
- Trusted Local Expertise
- Fast and Reliable Shipping
Description
The Neutrino-N series has an open, freely programmable architecture. With Dante enabled. Design the processor to your liking using the drag & drop software on Windows or macOS. Create your own personal DSP circuit diagram for your individual project requirements from a large selection of audio and logic DSP modules. Create up to 70 presets for individual modules (e.g. matrix mixer) or the entire project.
Optionally, the processors can be controlled by one or more TP8 touch panels and XWP Control (PoE). The app (ACX-Touch) available for download for Windows, macOS, iOS and Android can also be used for control. 3rd party devices such as video matrix switchers, scalers, projectors or other devices can be conveniently controlled via the app.
Specifications
- Input impedance - >10kΩ
- Output impedance - 50Ω
- Maximum level - +20dBu
- Frequency response - +/-0.15dB (20 to 20kHz)
- Dynamic range - 110dB
- Distortion - 0.002%(1kHz @ +4dBu
- Processor - 40-bit Floating point
- Sampling rate - 48kHz
- Analog converters - High-performance 24-bit
- Power - 90-240 VAC(50-60Hz)
- Dimensions 19“x1.75“x9"(483x44x229mm)
- Weight 11lbs/ 5kg
